What is a high brightness monitor?
In areas with bright ambient light, such as store windows, outdoors, or in brightly lit atriums, monitors with normal brightness backlights can be difficult to read. Wintouch offers a range of products with exceptionally strong backlights that are ideal for these conditions.
High Brightness Monitors are available in brightness levels from 700 cd/m² to 1500 cd/m² and in sizes ranging from 7 inches to 54.6 inches.High Brightness Monitors are equipped with a brightness control. In high temperatures or low ambient light conditions, the High Brightness Monitor will automatically and gradually reduce the screen brightness
high brightness monitor
Outdoors or in bright conditions, the brightness of the touch screen monitor must be increased to ensure a clear image.The number of nits emitted by the LCD touch screen is the primary factor in determining the perceived brightness of the touch screen monitor. A touch screen monitor brightness of approximately 200-350 nits works well indoors. Most LCD touch screens and touch screen monitors fall within this range. However, 400-700 nits is required for use in daylight conditions. Most importantly, sunlight readable industrial monitors require at least 1,000 nits or more to be viewed in direct bright sunlight. These High Brightness Monitors are available in 16:9 aspect ratio or 4:3 aspect ratio screens.
What is optical fit for high brightness monitor?
Some touch screen monitors cover the LCD touch panel with a layer of glass to prevent accidental or intentional damage. However, glass can also create unwanted glare and reflections. Internal reflections from the air gap between the glass and the LCD touch panel can further degrade image quality. To solve this problem, displays are optically bonded.
Optical bonding is the process of laminating the protective glass or touch screen panel to the LCD panel using an optical grade resin. This completely fills the air gap between the glass and the LCD touch panel. It not only eliminates internal reflections, but also improves contrast. This makes the screen look brighter and clearer in bright light conditions. Optical bonding also eliminates internal moisture and condensation. In addition, it will make the High Brightness Monitor more rugged and durable. Finally, an anti-reflective coating is applied to the outside of the glass. As a result, this will greatly reduce glare and surface reflections.
sunlight readable industrial monitor
For installations in indirect sunlight or reflective glare, our sunlight readable industrial monitor will most likely suffice. sunlight readable industrial monitor is also more cost effective than sunlight readable industrial monitor with 1,000 nits. The LCD screen of the sunlight readable industrial monitor has a brightness of 350 nits to 700 nits. the LCD touch panel also includes optical bonding.
Sunlight readable industrial monitors with optical bonding are also brighter than standard touch screen monitors. As a result, they produce better image quality under bright conditions. Although they are not as bright as High Brightness Monitors, sunlight readable industrial monito have the advantage of lower power consumption. This may be beneficial for portable or mobile applications.
High brightness Monitor/outdoor waterproof industrial monitor
Our Outdoor high brightness sunlight readable LCD monitor features waterproof stainless steel housings. These housings are ideal for factory washdown environments. In addition, they are ideal for outdoor use in inclement weather. Our panel mount housings are made of steel, stainless steel or aluminum. This allows them to be mounted flush.High Brightness Monitors can operate over a wider temperature range. Therefore, this extends the environment in which they can be used. In addition, the temperature range is an important factor to consider when using them outdoors. When we combine extreme operating temperatures with an outdoor waterproof enclosure, we ensure that your High Brightness Monitor will work even in the harshest humid and hot environments. We will also modify or customize any model to meet your exact requirements.
High brightness monitors are in widespread use around the world
Military, law enforcement, and manufacturing plants benefit from High Brightness Monitors. amusement parks, stadiums, public transportation, as well as construction and heavy equipment rely on sunlight readable industrial monitors. additionally, pipeline inspections, kiosks, marine, oil and gas, drones, and security applications all require outdoor High Brightness Monitors. When it counts, you can count on wintouch touch screen monitors to provide the best weatherproof High Brightness Monitor solution for your specific needs.
