Touch screen panel pc
Touch screen panel pc Display Properties
Touch screen panel PC enhance user experience. Equipped with capacitive touch screens, the human-machine interface between users is more convenient and easy to operate. Designed for outdoor conditions, the high-brightness display ensures clear visibility even in bright sunlight, making it suitable for outdoor installation. The industrial design makes the touch screen panel PC last longer and can withstand frequent use. Flexible viewing angles ensure visibility at different angles and enhance usability in different environments. From compact to large-size touch screen panel PC, meet specific application needs. The touch screen has different waterproof levels, such as IP65 waterproof level for the front panel and even waterproof for the entire machine to ensure reliability in harsh conditions.
10.1″ Aluminum IP65 Rugged Panel Pc
- WTPC101-3566RK3566
- 1.8GHz, 2GB+16GB, DC1, HDMI1, USB 3.01, TYPE-C1, LAN1, TF Card Slot1, Aluminum back pane
- Capacitive touch screen, 1280*800 resolution, 300 nits
- Android 11 or Linux system
7″ Android AIO Rugged Panel Pc
- WTPC070-RK3566
- RK3566/1.8GHz, 2GB+16GB, DC1, VGA1, USB 2.02,LAN1, TF Card Slot*1, Aluminum back panel
- Capacitive touch screen, 1024*600 resolution, 300 nits
- Android 11 or Linux system
10.1″ Windows Capacitive Rugged Panel Pc
- WTPC101-J1900
- J1900/2GHz, 4GB+64GB, DC1, HDMI1, USB 2.02, VGA1, LAN1, RS4851
- Capacitive touch screen, 1280*800 resolution, 300 nits
- Windows
13.3″ Android LED NFC Panel Pc
- WTPC133-3568
- RK3568/2.0GHz, 2GB+16GB, DC1, HDMI1, USB 2.01, USB 3.01, LAN*1,LED Light
- Capacitive touch screen, 1920*1080 resolution, 300 nits
- Android 11 or Linux system
Touch screen panel pc touch operation
Projected capacitive touch (PCAP) is a very accurate touch screen technology. Surface capacitive touch is more commonly used on the market, which only supports single-point touch operation. Projected capacitive touch supports multiple points of touch at the same time. For example, touch screen panel pc sliding or zooming in and out can be achieved through different gestures; Touch screen panel pc realizes the convenience of human-computer interaction interface operation.
Touch screen panel pc high brightness
The standard brightness range of a normal touch screen panel PC is 250-450 nits, which is suitable for indoor use; while a high brightness touch screen panel PC with sunlight readability usually has a brightness of 1000 nits, which can ensure that it can be clearly seen in bright sunlight outdoors or in places with glaring sunlight. High brightness touch screen panel PCs can meet the requirements of outdoor installations, such as digital signage and interactive kiosks. Common examples include bus stop signs, outdoor parking lot access systems, etc. At the same time, panel pc manufacturer‘s touch screen panel pc also has anti-glare and anti-reflection features, making it more clearly visible even in glaring sunlight.
The lifespan of Touch Screen panel PC
Typically, the service life of a touch screen panel pc is 50,000 hours, thanks to the careful design of the industrial touch screen panel pc and the rugged touch screen that can withstand frequent use. The durability of the industrial panel pc can minimize maintenance costs and maximize the longest operating time.
Visual angle of Touch screen panel PC
When using a touch screen panel PC, you may not be able to view the screen directly at the optimal 90° vertical viewing angle, so flexible viewing angles are essential to ensure visibility at different angles. Touch screen panel PCs offer a 178° viewing angle, enhancing accessibility in different environments.
Resolution and size of touch screen panel PC
The size of touch screen panel pc ranges from compact 7 inches to large size to meet different application requirements; the touch screen panel PC conventional sizes include 7″, 10″, 12″, 15″, 17″, 19″, 26″, etc., which can be customized according to the requirements; the touch screen panel PC resolution varies according to the size, and the conventional resolutions are 1024600 & 800600 & 1280800 & 1027768 & 1920*1080. There are many choices to meet specific application requirements from compact interface to widescreen display.
Protection level of touch screen panel PC
The protection level of touch screen panel pc industry is very important, including the touch screen panel pc front panel IP waterproof and the whole machine waterproof, as well as the interface waterproof. Considering the outdoor or ship use, touch screen panel pc can meet the different IP levels of waterproof, dustproof and shockproof to ensure the reliability in harsh environment.
